Manufacturer:Schneider
Product Number:TM3TM3
Product Type:Analog IO Module
Origin:Sweden
Dimensions:90 x 70 x 23.6mm
Weight:0.115kg
Views:44
Payment Methods:T/T, PayPal, Western Union
Condition:New & In Stock
Warranty:1 Year
Lead Time:1-3 Working Days
Certificate:COO
Courier partners:DHL, UPS, TNT, FedEx and EMS.
Business hours:7*24
The Schneider TM3TM3 is a versatile analog I/O module within the Modicon TM3 series, developed to expand the analog signal handling capabilities of Schneider Electric’s modular control systems. This module provides both analog input and output channels in a compact form, ideal for process control and monitoring applications where high signal accuracy and resolution are essential.
Engineered for integration with Modicon TM3 and M221/M241/M251 logic controllers, the TM3TM3 enables precise data acquisition and analog output control, supporting current and voltage signals. Its modular design, rugged construction, and seamless connectivity make it well-suited for industrial automation environments.
| Item | Specification |
|---|---|
| Model Number | TM3TM3 |
| Module Type | Analog I/O Module |
| Analog Inputs | 2 channels |
| Analog Outputs | 2 channels |
| Input Signal Type | Voltage (0–10 V), Current (0–20 mA, 4–20 mA) |
| Output Signal Type | Voltage (0–10 V), Current (0–20 mA, 4–20 mA) |
| Resolution | 12 bits |
| Conversion Time | ≤10 ms |
| Accuracy | ±0.5% full scale |
| Isolation | Galvanic isolation between channels and bus |
| Operating Voltage | Supplied via system bus |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | 90 x 70 x 23.6mm |
| Weight | 0.115 kg |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
| Certifications | CE, cULus, RoHS, EAC |
| Connection Type | Removable spring or screw terminals |
| Configuration Tool | EcoStruxure Machine Expert (SoMachine) |
Process Control Systems
Temperature and Pressure Monitoring
HVAC and Building Automation
Water and Wastewater Treatment
Energy Management Systems
Food and Beverage Automation
Packaging Machines
Oil & Gas Instrumentation
Dual I/O Functionality: Supports both analog input and output in one compact module.
High Accuracy: 12-bit resolution with ±0.5% full scale ensures precise measurements and control.
Flexible Signal Types: Accepts and delivers both voltage and current signals.
Galvanic Isolation: Protects against electrical interference and enhances signal integrity.
Plug-and-Play Integration: Easily connects to TM3 and Modicon controllers with minimal configuration.
Compact and Lightweight: Ideal for applications with space constraints.
DIN Rail Mounting: Enables simple and secure installation in standard enclosures.
EcoStruxure Compatible: Seamless configuration using Schneider’s powerful automation software.
What type of signals does the TM3TM3 support?
It supports both voltage (0–10 V) and current (0–20 mA or 4–20 mA) for inputs and outputs.
How many analog input and output channels are provided?
The module includes 2 analog inputs and 2 analog outputs.
What is the resolution of this module?
It provides 12-bit resolution for both input and output channels.
Is the module isolated?
Yes, it offers galvanic isolation between the channels and the communication bus.
What software is used to configure the TM3TM3?
It is configured using EcoStruxure Machine Expert (formerly SoMachine).
Can I use this module with M221 or M241 controllers?
Yes, it is fully compatible with Modicon M221, M241, and M251 controllers.
What is the accuracy of analog signal handling?
The module provides ±0.5% full-scale accuracy.
Is it suitable for industrial use?
Yes, it is designed to operate in harsh industrial environments with high reliability.
Does it support hot-swapping?
No, modules should be connected/disconnected with power off.
How is the module powered?
It is powered via the system bus from the main controller or base module.
