Emerson KJ4002X1-BC1 TOP 4 WIDE VERTICAL CARRIER

The Emerson KJ4002X1-BC1 TOP 4 Wide Vertical Carrier is an industrial automation component designed to provide secure housing and connectivity for various control modules within Emerson DeltaV and related automation systems. It serves as a vertical carrier, ensuring organized module installation and reliable electrical connections. Its robust design supports high-density module arrangements, enabling efficient use of panel space while maintaining system reliability and operational safety.

Product Parameters

Product Applications

• Centralized control systems for chemical, oil & gas, and power generation industries.

• Housing and connecting multiple control modules within DeltaV automation racks.

• High-density process control panels requiring secure vertical mounting of modules.

• Industrial environments demanding reliable module interconnectivity and maintenance accessibility.

• Upgrading or expanding existing DeltaV installations with additional module capacity.

Product Advantages

• High Density Design: Supports multiple modules in a compact vertical configuration.

• Reliable Electrical Connectivity: Ensures secure and stable signal and power distribution to modules.

• Ease of Maintenance: Removable and accessible design facilitates module replacement without disrupting other components.

• Durable Construction: Resistant to industrial vibrations, temperature fluctuations, and humidity.

• Standardized Compatibility: Compatible with a wide range of Emerson DeltaV modules and related equipment.

• Safety Compliance: Meets international industrial safety standards (CE, UL).

FAQ

• Q1: Can the KJ4002X1-BC1 carrier support mixed module types in a single vertical stack?

  A1: Yes, it supports compatible DeltaV and KJ4000 series modules as long as they adhere to standard slot dimensions.

• Q2: What is the maximum current per slot?

  A2: The carrier is rated for up to 5A per slot at 24VDC nominal.

• Q3: Can this carrier be installed in a horizontal orientation?

  A3: No, it is specifically designed for vertical installation to ensure proper module alignment and connectivity.

• Q4: Is there a recommended spacing between carriers in a multi-rack setup?

  A4: A minimum of 50 mm clearance is recommended for ventilation and maintenance access.

• Q5: Does the carrier include integrated grounding?

  A5: Yes, it provides grounding points compatible with standard Emerson rack systems.

• Q6: Are there any limitations on module weight per slot?

  A6: Each slot can accommodate standard DeltaV module weights; excessive weight beyond specifications may compromise mechanical integrity.

• Q7: What type of connector interface is used for module connections?

  A7: Standard Emerson bus connectors are used for secure electrical interfacing.

• Q8: Can the carrier operate in high-humidity environments?

  A8: Yes, it can handle 5% to 95% relative humidity, non-condensing.

• Q9: Is the carrier compatible with KJ4000 Rev A and Rev B modules?

  A9: Yes, it is designed for compatibility across multiple KJ4000 revisions.

• Q10: What maintenance is required for the carrier?

  A10: Routine inspection for dust accumulation and visual checks for connector wear are recommended; no internal servicing is needed.
