Schneider BMXXBP0600 Backplane

The Schneider Electric BMXXBP0600 is a 6-slot backplane designed for the Modicon M340 automation platform. This backplane serves as the foundational structure for assembling a modular Programmable Logic Controller (PLC) system, allowing the integration of various modules such as processors, power supplies, I/O modules, and communication interfaces. Its design ensures reliable electrical connections and mechanical stability, facilitating efficient system configuration and maintenance.

Technical Specifications

Product Applications

The BMXXBP0600 backplane is utilized in various industrial and infrastructure automation scenarios, including:

• Manufacturing Plants: Integration of control systems for assembly lines and machinery.

• Water and Wastewater Treatment: Management of pumps, valves, and monitoring systems.

• Energy Sector: Control systems for substations and renewable energy installations.

• Transportation: Automation systems for railways, airports, and traffic management.

• Building Management: HVAC control, lighting systems, and access control.

• Food and Beverage Industry: Automation of processing, packaging, and distribution systems.

Product Advantages

• Modular Design: Supports up to six modules, allowing flexible system configuration.

• Robust Construction: Designed to withstand industrial environments with resistance to dust, gas, and moisture.

• Versatile Mounting: Compatible with DIN rail, panel, and plate mounting, facilitating easy installation.

• High Compatibility: Works seamlessly with a range of Schneider Electric modules, ensuring system scalability.

• Efficient Power Distribution: Provides reliable power and data communication across all connected modules.

• Compact Size: Space-saving design suitable for installations with limited space.

• Compliance and Certification: Meets international standards and certifications, ensuring safety and reliability.

Frequently Asked Questions (FAQ)

1. What modules are compatible with the BMXXBP0600 backplane?

   It is compatible with BMXP34 processors, BMXCPS power supplies, I/O modules, and specific application modules within the Modicon M340 series.

2. Can the backplane be mounted on different surfaces?

   Yes, it supports DIN rail, panel, and plate mounting options.

3. What is the maximum operating temperature?

   The backplane operates effectively within a temperature range of 0°C to +60°C.

4. Is the backplane suitable for harsh environments?

   Yes, it has environmental resistance ratings for gas, dust, salt, and mold, making it suitable for industrial applications.

5. Does the BMXXBP0600 support hot-swapping of modules?

   While some modules may support hot-swapping, it is recommended to refer to individual module specifications for confirmation.

6. What is the power consumption of the backplane?

   The backplane consumes 1.5 W of power.

7. Is the backplane certified for international use?

   Yes, it holds certifications such as CE, UL, CSA, and others, complying with international standards.

8. What is the protection rating of the backplane?

   It has an IP20 protection rating, indicating protection against solid objects greater than 12.5 mm and no protection against liquids.

9. Can the backplane be used in hazardous locations?

   Yes, it is certified for use in ATEX Zone 2/22 and IECEx Zone 2/22 hazardous environments.

10. What is the warranty period for the BMXXBP0600?

    The backplane comes with an 12-month warranty from the date of purchase.
