Vibro-Meter TQ902 111-902-000-011 A1-B1-C72-D2-E10000-F2-G9800-H10 Proximity Sensor
Item Number:CA134 144-134-000-612
Brand: Spare
Lead Time: In stock
Description:Proximity Sensor
Payment: T/T
Product Description
The TQ902 111-902-000-011 (Order No. A1-B1-C72-D2-E10000-F2-G9800-H10) is a proximity sensor designed for non-contact vibration and axial displacement measurement in equipment such as turbines, compressors, pumps and fans. It is used with the EA902 extension cable and IQS900 signal conditioner to provide voltage or current output and is suitable for high temperature and hazardous environments (such as explosive gas areas).
Note: The TQ902 and TQ912 sensors have the same specifications and characteristics, but different installation requirements.
Function
- Non-contact measurement: Based on eddy current technology, the TQ902 111-902-000-011 can detect the displacement, vibration or rotation speed of metal targets without physical contact.
- Multiple range options: The TQ902 111-902-000-011 provides 2 mm or 4 mm linear measurement range.
- Signal output: The TQ902 111-902-000-011 outputs voltage (4–20 mA) or current (0–10 V) through the IQS900 signal conditioner, supporting long-distance transmission of 1 km.
- Temperature compensation: The TQ902 111-902-000-011 has a built-in temperature compensation circuit and can measure in the range of -40°C to 180°C.
- High frequency response: DC to 20 kHz (-3 dB)
Product Advantages
✔ High-precision measurement: sensitivity up to 8 mV/µm (2 mm range), excellent linearity
✔ Extreme environment adaptability: 180°C high temperature resistance, explosion-proof, IP68 protection
✔ Range configuration: optional 2 mm or 4 mm range, multiple cable lengths
✔ Compliance: Meets API 670 standard
Specification
|
Parameter |
Specification |
|
Model Number |
TQ902 |
|
Ordering Number |
111-902-000-011 A1-B1-C72-D2-E10000-F2-G9800-H10 |
|
Measurement Range |
0.08 or 0.16 in | 2 or 4 mm |
|
Operating Temperature |
-40 to 356°F (-40 to 180°C) |
|
Integrated Cable Length |
1.6, 3.3, 4.9, 6.6, or 16.4 ft (0.5, 1.0, 1.5, 2.0, or 5.0 m) |
|
Protection Rating |
IP68 |
|
Mounting Type |
Standard-mount (vs. TQ912 reverse-mount) |
|
Output Signal |
Voltage or current (via IQS900 conditioner) |
|
Certifications |
API 670 5th Ed., Ex versions for hazardous areas |
FAQ
Q: What is the brand?
A: Spare
Q: What is the type?
A:Proximity Sensor
Q: What is the warranty?
A: 1 year
Q: Where is the shipping location?
A: Xiamen
Q: What is the payment method?
A: T/T
Q: Why choose us?
A: We are the supplier for industrial automation spare parts,We speciaized in PLC DCS and TSl system modules and spare parts for 10 years, With our professional expertise and extensive experience, we are well-equipped to meet your requirements.
